Based on our first ever AWD bike, this bike can slice and dice the trails but climb like a mule. The proprietary state-of-the-art AWD system integrates cleanly into this 27.5+ split frame design using a custom 150mm travel 35mm stanchion suspension fork and SRAM GX Eagle component group. The simple design allows for a convertible wheelset so you can go with a 29er setup and 2″ rubber as well giving you one of the most unique and versatile bikes on the market.
CHRISTINI AWD System
– Handlebar-mounted shift on the fly AWD engagement switch
– 7075 Spiral-Drive aluminum bevel and pinion gears
–7075 aluminum interlocking clutch
– Tubular aluminum driveshafts
– Coated steel universal joints
– Stainless sealed cartridge bearings
– Total AWD system weight is 2.3 lbs
| FRAMESET | |
| Frame | 6061 T6 Aluminum with integrated direct AWD system |
| Fork | CHRISTINI/RockShox Revelation RC 35mm 150mm travel |
| HEADSET | |
| Headset | CHRISTINI integrated headset with sealed bearings. |
| WHEELS | |
| Front Hub | CHRISTINI AWD one way clutching |
| Rear Hub | Sun Ringle SRC Boost 148mm thru-axle XD Drive |
| Rims | Sun Ringle Duroc 40 Rim – Tubeless setup |
| Spokes | Wheelsmith DB black |
| Tires | 27.5+ x 2.8 Terrene |
| DRIVETRAIN | |
| Crank | SRAM GX Eagle DUB |
| Chainring | SRAM X-Sync 2 Eagle 32 |
| Cassette | SRAM GX 12-Speed 10-42t Cassette |
| Shifter | SRAM GX 12-Speed Shifter |
| Rear Derailleur | SRAM GX 12-Speed Rear Derailleur |
| Chain | PCX1 Chain |
| Pedals | Race Face Chester composite platform |
| BRAKES | |
| Levers | SRAM G2 Hydraulic |
| Calipers | SRAM G2 Hydraulic |
| Rotors | SRAM Centerline 203mm Front/180mm Rear |
| COCKPIT | |
| Bars | RaceFace 35 x 20mm Riser |
| Stem | RaceFace 35 x 60mm Length |
| Seatpost | PNW 150mm External Dropper |
| Saddle | WTB Speed Pro Gel |
| Grips | Ergon GP1 |
| WEIGHT | 27 LBS |
| SIZE | A | B | C | D | E | F |
| Small (fits like 16″) | 69° | 73° | 22.5″ | 16″ | 42.2″ | 12.5″ |
| Medium (fits like 18″) | 69° | 73° | 23.5″ | 18″ | 43.7″ | 12.5″ |
| Large (fits like 20″) | 69° | 73° | 24.5″ | 20″ | 45″ | 12.5″ |
| **All dimensions are measured with 26 x 4.8 tire | ||||||
| **Addition of 100mm suspension changes the headtube angle to 67 degrees. | ||||||
