CHRISTINI AWD FAT 4 GX



awd-fat-4-left-side-black-tires

Taken from a design that first started with an successful idita bike race, the AWD 4″ Fat gets all the benefits of AWD with a nimble 4″ split frame design and a great SRAM GX build kit.  The bike can slice and dice the trails but climb like a mule. The proprietary AWD system integrates cleanly into this 4″ split frame Fat bike without the use of a Universal joint to transfer the power to the front of the bike.   This bike will help you climb hills you never thought possible with a bike.

CHRISTINI AWD System
– Handelbar mounted AWD engagement switch.
– Spiral-Drive aluminum bevel and pinion gears.
– Aluminum interlocking clutch.
– Tubular aluminum drive shafts.
– Coated steel universal joints.
– Stainless sealed cartridge bearings.
– Total AWD system weight is 2.3 lbs.

CHRISTINI AWD FAT 4 GX

MSRP $2995

BUY NOW!

FRAMESET

Frame 6061 T6 Aluminum with integrated direct AWD system
FORK
Fork CHRISTINI Carbon FAT 135mm

HEADSET

Headset CHRISTINI integrated headset with sealed bearings.
WHEELS
Front Hub CHRISTINI AWD one way clutching
Rear Hub Carver 177mm thru-axle XD Drive
Rims Sun Ringle Mulefut 80m Rim – Tubeless setup
Spokes Wheelsmith DB black
Tires Vee RubberAvalanche 26×4 Pure Silca (Tan/Black)

DRIVETRAIN

SRAM GX Fat Bike Kit SRAM GX Fat Bike 1X11 Kit
Crank SRAM GX 1400 Crankset – 170mm X-Sync 30 Tooth
Cassette XG-1150 Cassette
Rear Deraileur GX Rear Derailleur
Chain PCX1 Chain
Bottom Bracket SRAM GXP Bottom Bracket
Pedals Wellgo Mtn WPD-95B Clipless with platform

BRAKES

Levers SRAM Level Hydraulic (or AVID FR-7 Cable)
Calipers SRAM Level Hydraulic (or AVID BB7 Cable)
Rotors SRAM Centerline 180mm

COCKPIT

Bars RaceFace Aeffect 35mm Riser
Stem RaceFace Aeffect 35mm 60mm
Seatpost RaceFace Turbine 31.6
Saddle WTB Pro Gel
Grips Ergon GP1

WEIGHT

18″ @ 33 LBS

Geometry

geometry-hardtail
Size A B C D E F
Small (fits like 16″) 71° 73° 22.5″ 16″ 43″ 12.5″
Medium (fits like 18″) 71° 73° 23.5″ 18″ 43.5″ 12.5″
Large (fits like 20″) 71° 73° 24.5″ 20″ 44.7″ 12.5″
*All dimensions are measured with Vee Rubber 26×4 tire
